250 Bar 300 Bar Air Compressor High Pressure Air Compressor 30MPa
- Price
- US $3000-7000
- Model
- HPP
- MOQ
- 1 piece
Item specifics
- Power
- 55/75 kw
- Displacement
- 3/5/6 m3/min
- Pressure
- 150/250/300 Bar
Review
Description
DG series middle-high pressure piston air compressor have skid-mounted, portable, electric,diesel-moving four categories, Composed of the compressor, electric motor (diesel), clutch, piping systems, operating systems, electrical equipment, auxiliary equipment, and other components.High-Pressure Air Compressor
Mainly used for pipeline pressure test of oil exploration, sweeping lines, gas lift, and other projects, as well as membrane nitrogen, heat mining, injecting natural gas for the bottom of well, oil and gas, and national defense industry. gas stations, etc., superior performance, high degree of automation.
Also can be used as construction requires displacement of less than 20m3 / min, and the exhaust pressure is less than 35MPA gas source or origin station car.
| Model | Pressure (mpa) | Powder (kW) | Displacement (m³/min) | Series (n) | Lubrication Method |
| HPP-3/100-DG | 10 | 55-6 | 3 | 4 | Splash |
| HPP-3/150-DG | 15 | 55-6 | 3 | 4 | |
| HPP-3/250-DG | 25 | 55-6 | 3 | 4 | |
| HPP-5/100-DG | 10 | 75-6 | 5 | 4 | |
| HPP-5/150-DG | 15 | 75-6 | 5 | 4 | |
| HPP-5/250-DG | 25 | 75-6 | 5 | 4 | |
| HPP-5/40-DG | 4 | 75-6 | 5 | 3 | |
| HPP-5/60-DG | 6 | 75-6 | 5 | 3 | |
| HPP-6/40-DG | 4 | 75-6 | 6 | 3 | |
| HPP-6/60-DG | 6 | 75-6 | 6 | 3 |
